MIPI TFT
The MIPI Display Serial Interface (MIPI DSI®) defines a high-speed serial interface between a host processor and a display module. The interface enables manufacturers to integrate displays to achieve high performance, low power, and low electromagnetic interference (EMI) while reducing pin count and maintaining compatibility across different vendors. Designers can use MIPI DSI to facilitate brilliant colour rendering for the most demanding imagery and video scenes and to support transmission of stereoscopic content.
View our MIPI TFT Display Range
| Product Number | Size (inch) Sort descending | Resolution | Viewing Angle | Dimensions | Brightness | Operating Temp |
|---|---|---|---|---|---|---|
| DMT043WVNMCMI-1B | 4.30" | 480 x 800 | 80/80/80/80 | 3.93mm x 62.50mm x 105.55mm | 405 | -20°C-70°C |
| DMT050HDNMCMI-1A | 5.00" | 720 x 1280 | 80/80/80/80 | 4.20mm x 135.65mm x 78.56mm | 420 | -20°C-70°C |
| DMT055HDNMCMI-1H | 5.50" | 720 x 1280 | 80/80/80/80 | 4.75mm x 86.04mm x 144.96mm | 360 | -20°C-70°C |
| DMT070F3NMCMI-1A | 7.00" | 1200 x 1920 | 85/85/85/85 | 4.00mm x 176.78mm x 119.46mm | 300 | -10°C-60°C |
| DMT101F3NMCMX-1A | 10.10" | 1200 x 1920 | 85/85/85/85 | 4.33mm x 159.00mm x 244.60mm | 550 | -10°C-50°C |
Why use Densitron’s MIPI TFT Solutions?
- Enabling integration of high resolution displays.
- Low EMI.
- Trending interface amongst latest Embedded architectures.
- Ideal for high clarity, colour rich applications such as Broadcast or Pro Audio.
Customisation
For the most challenging environments we offer a wide range of innovative customisation options allowing us to tailor components to your exact requirements.
Cover Lens Customisation
Choosing from material options such as soda lime, chemical and heat strengthened, tempered and toughened glass and PMMA, Polycarbonate and Optolite™ high scratch resistant plastics, our team can pinpoint the ideal solution. Our bespoke service also includes enhancement such as Anti-Glare (AG), Anti-Reflection (AR) and Anti-Smudge (AS) optical treatments. Finally, colour and graphic logo printing, circular, rectangular and free-form cut-out detailing can fully customise your monitors.
Haptic Touch Option
As the ultimate in sensory and intuitive user experience, delivering product differentiation from competitors, we offer integrated Haptic feedback technology to our TFT touch sensors. Users experience added satisfaction of a tactile sensation of simulating clicks and vibrations through the touch screen, giving the enhanced perception of using physical buttons and switches.
Optical Bonding
When clarity and functionality is essential to create the best end-user experience, Optical Bonding offers the perfect solution for increasing visibility and durability in light-challenging and harsh environments.
Embedded Solutions
Specially designed embedded SBC solutions for our AMOLED displays, contain all the essential hardware, software, electronics and interface drivers to reduce your development cycle and speed up time to market.
EMI & Noise Immunity
When maintaining maximum performance, reliability and output efficiency is essential, our in house engineer designed and developed protective EMI shields and ground pads to limit Electromagnetic Interference (EMI) and provide noise immunity.
